Professional-Grade Compliance Tool for Schuko (Type F) Plugs & Sockets
The DIN 49440-L2 is a precision-engineered test gauge designed to validate critical safety dimensions of German Schuko plugs and sockets in strict compliance with DIN 49440 standards. This essential quality control instrument ensures proper earthing contact, pin alignment, and mechanical integrity for manufacturers, certification labs, and importers targeting the European market.
Key Features & Technical Advantages
✔ Full DIN 49440 Compliance - Verifies all mandatory dimensions for Type F (Schuko) connectors
✔ Precision Measurement - Tests:
Pin diameter (4.8mm ±0.01mm for live/neutral)
Earth contact strip alignment (10mm width tolerance)
Insertion force (10-20N per EN 60320)
✔ Industrial Durability - Hardened chromium steel (58 HRC) with anti-wear coating
✔ Certification Ready - Includes DAkkS-traceable calibration certificate
Critical Safety Tests:
Child safety shutter operation
Contact pressure consistency
Resistance to overheating
Technical Specifications
| Parameter | Specification |
|---|---|
| Standard | DIN 49440 |
| Material | 1.2842 Tool Steel |
| Accuracy | ±0.005mm |
| Compliance | VDE, CE, ENEC, GS Mark |
